Ex ia Photoelectric Detector
Ex ia Photoelectric Detector
Certification Unit:
Must be used with the loop isolation module. No accumulation and no address function
Formal approval of fire protection products of the Ministry of Internal Affairs of Taiwan
Explosion-proof mark | |
| Explosion Proof Mark | EX |
| Gas Explosion-proof Type | ia |
| Gas Hazardous Location Group | IIC |
| ambient temperature Classes for Gas | T5 |
| EPL: Equipment Protection Level-Gas | Ga |
| IP Enclosure Ratings | IP42 |
Product specifications | |
| Body Size | Ø(mm)diameter 100 Width(W) 48 |
| Electric Current | DC12~30V |
| Operating Temperature | -10~+50 |
| Weight | 106g |
| Product source | Imported goods |
Description:
The dual-color LED lights provide a 360-degree visible field of view.
Use remote indicator light output, stable signal, convenient construction and installation.
With ORB-MB-50018-APO base.
Detachable dust chamber is easy to maintain.
Intimate reminder: It needs to be used with explosion-proof circuit isolation module.
Use remote indicator light output, stable signal, convenient construction and installation.
With ORB-MB-50018-APO base.
Detachable dust chamber is easy to maintain.
Intimate reminder: It needs to be used with explosion-proof circuit isolation module.
Recommend
Ex ia Temperature Detector
Certification Unit:
2 kinds, differential and constant temperature (60 ° C)
Must be used with the loop isolation module. No accumulation and no address function
Formal approval of fire protection products of the Ministry of Internal Affairs of Taiwan
Ex ia Temperature Detector
Certification Unit:
Differential and constant temperature (60 ℃).
2 types; action temperature: +30°C within 30 seconds.
2 types; action temperature: +30°C within 30 seconds.
Must be used with the loop isolation module. No accumulation and no address function
Formal approval of fire protection products of the Ministry of Internal Affairs of Taiwan
Ex ia Smoke Detector
Certification Unit:
photoelectric.
Must be used with loop isolation modules.
Ministry of the Interior fire department type approval
Fixed Temperature Heat Detector
Certification Unit:
Ministry of the Interior fire department type approval
Applicable temperature:57℃(302-EPM-135)/90℃(302-EMP-194)
Loop isolation module
Up to 6 sensors can be cascaded
Working temperature: 0~50°C, relative humidity below 95%
